FOR ENGINEERS
FRP Repair Specifications & Sample Design Details
Guide specifications for the three QuakeWrap® systems, the Composite Strengthening System, PileMedic® and SPiRe®+, plus the grout specification and typical design details. Your engineer of record can edit, adapt and issue them.
- Guide specifications for all three QuakeWrap® systems
- Typical details for piles, seawalls, beams and walls
- Warranty terms for each product line

START HERE
Three System Specifications
QuakeWrap® publishes a guide specification for each of its three systems. Download the one that fits the structure. Typical details and the grout specification are further down the page.
- PDF · 11/26 · 21 PAGES QuakeWrap® Composite Strengthening System Carbon and glass FRP fabrics bonded to concrete and masonry (formerly Wet Layup)
- PDF · DEC. 1, 2015 · 10 PAGES PileMedic® System FRP laminate jackets for timber, concrete and steel piles and columns
- PDF · V1, 11/23 · 14 PAGES SPiRe®+ System FRP panels for seawalls, sheet piles, beams, columns and walls
COMPOSITE STRENGTHENING SYSTEM
QuakeWrap® Composite Strengthening System Specification
Formerly called the wet layup specification. It covers carbon and glass FRP fabrics saturated with epoxy in the field and bonded to concrete and masonry beams, slabs, columns and walls. Written in CSI three-part format and referencing ACI 440.2R-23, it sets system qualification, fabric and resin properties, surface preparation, installation, inspection, pull-off testing and repair of defects.
ABOUT WET & DRY LAYUP FRP- PDF · 11/26 QuakeWrap® Composite Strengthening System Specification Carbon and glass fabrics, QuakeBond™ resins, installation and inspection, 21 pages
- DATA SHEETS Fabric & Resin Data Sheets Properties for each QuakeWrap® fabric and QuakeBond™ resin
- FABRIC PROPERTIES Wet & Dry Layup Fabrics Compared Carbon vs. glass, laminate properties and resin coverage
PILEMEDIC®
PileMedic® Specification & Typical Details
For repair and strengthening of timber, concrete and steel piles and columns with PileMedic® laminates. The generic specification is written in a non-proprietary format: delete the sections that do not apply and keep the one option you plan to use. The details show typical layers, overlaps, spacers, fill and terminations. They are not for construction.
ABOUT PILEMEDIC®- PDF · DEC. 1, 2015 Generic PileMedic® Specification Pile and column repair with FRP laminate jackets, 10 pages
- WORD Generic PileMedic® Specification (editable) Same specification in MS Word
- 2 SHEETS Typical Details: Timber Piles Two layers plus overlap, GFRP bars and spacers per design, epoxy plug and grout annulus
- 1 SHEET Typical Detail: Timber Pile With Low-Viscosity Resin B2408G fabric with QuakeBond™ 320LV resin injected into the pile
- 1 SHEET Typical Details: Concrete Piles Circular and octagonal cross sections
- 5 SHEETS Typical Details: Steel Piles & ShearWrap™ Plumb and batter piles, cap termination and ShearWrap™ load transfer
- 1 SHEET Typical Detail: Steel H-Piles & ShearClamp™ ShearClamp™ quantity set by design
- 1 SHEET Typical Detail: Single Layer for Protection Only One layer of PileMedic® where no strengthening is needed
- INSTALLATION PileMedic® User Manual & Installation Guide Rapid pile repair kit manual prepared for the U.S. Army Corps of Engineers
FROM THE PILEMEDIC® SPECIFICATION
Nominal PileMedic® Jacket Values
Nominal confining pressure and longitudinal steel equivalent for a 2-ply PileMedic® jacket, from the generic specification dated December 1, 2015. Steel equivalent is Grade 60 bars spaced around the pile perimeter. Check values against the current product data sheet before design.
| Pile diameter | Glass: confining pressure | Glass: steel equivalent | Carbon: confining pressure | Carbon: steel equivalent |
|---|---|---|---|---|
| 10 in. | 645 psi | #4 at 3 in. | 1,050 psi | #4 at 3 in. |
| 12 in. | 535 psi | #4 at 3 in. | 875 psi | #4 at 3 in. |
| 15 in. | 430 psi | #4 at 3 in. | 700 psi | #4 at 3 in. |
| 18 in. | 355 psi | #6 at 7 in. | 580 psi | #6 at 7 in. |
| 24 in. | 265 psi | #6 at 7 in. | 435 psi | #6 at 7 in. |
| 36 in. | 180 psi | #8 at 11 in. | 290 psi | #8 at 11 in. |
| 48 in. | 130 psi | #8 at 11 in. | 220 psi | #8 at 11 in. |
| 60 in. | 107 psi | #8 at 11 in. | 175 psi | #8 at 11 in. |
FILL MATERIAL
Choosing the Fill for a PileMedic® Jacket
The generic specification offers three fill options, chosen by the width of the annular space between the pile and the jacket and the condition of the pile.
| Fill | Annular space | When to use it | Structural note |
|---|---|---|---|
| QuakeBond™ 320LV low-viscosity resin | Under ¼ in. | Circular piles that are cracked or decayed, so resin fills the voids | Bonds the jacket and added bars to the pile for flexure |
| PileMedic® UW epoxy grout | ¼ in. to 1 in. | Wider annulus; about 180 to 225 lb of silica per 5 gal of epoxy | Same structural benefit as low-viscosity resin |
| PileMedic® UW underwater grout | Over 1.5 in. | Large annular space | Bond to the jacket is conservatively ignored for flexure |
Not sure which fill or detail fits?
Send the pile size, material and damage. Our team will recommend the right QuakeWrap® system and provide specifications for your engineer.
SPIRE®+
SPiRe®+ Panel Specification & Typical Details
For SPiRe®+ FRP panels that protect and reinforce steel sheet piles, concrete and timber walls, beams and columns. The specification is in CSI three-part format under Division 03. The details are marked Not for Construction.
ABOUT SPIRE®+- PDF · V1, 11/23 Section 03 10 00.01: QuakeWrap SPiRe®+ Panel System Panels, fill, anchors, installation, inspection and warranty, 14 pages
- WORD Section 03 10 00.01 (editable) Same specification in MS Word
- 4 SHEETS · 08/20/2023 Typical Details: SPiRe®+ Seawall Repair Panel properties, overlap, vertical placement and strongback details
- 1 SHEET Typical Details: Beams Repaired With SPiRe®+ Corner repair, bolts and GFRP bars drilled and epoxied, FRP angles
- 1 SHEET Typical Detail: New Retaining Wall Cast With SPiRe®+ Stay-in-place SPiRe®+ panels with through bolts and starter bars
SUPPORTING SPECIFICATIONS
Grout & Form-A-Tube® Specifications
The grout specification is not a separate system. It supports the PileMedic® and SPiRe®+ systems and covers the cementitious grout, epoxy grout and cellular concrete placed with them. The Form-A-Tube® installation specification covers the reusable PVC form for pile encapsulation.
ABOUT FORM-A-TUBE®SUBMITTALS
What the PileMedic® Specification Asks the Contractor to Submit
A preview of the submittal section, so your engineer knows what to expect. Edit it to suit the project.
-
Product data
Data sheets for the FRP laminate, fill resin, adhesive resin and accessories, plus safety data sheets.
-
Design and shop drawings
Confining pressure calculations, details per local codes, and shop drawings showing installation steps, spacer sizes, overlaps and fill, sealed by a professional civil engineer.
-
Certifications
An ASTM F2207 test report for confining pressure, full-scale test summaries, and material certifications showing laminate fabrication and resin manufacture dates.
-
Quality records
Daily installation reports with air and water temperatures and the lot numbers of laminates and resins used on each pile.
Need a project-specific specification?
Tell us about the structure and we will send the specifications and details your engineer needs.
WARRANTY
What the Product Warranties Cover
SPiRe®+ panel system: the specification calls for a two-year material warranty against defects. Extended material warranties may be available from the manufacturer for an added fee and may require periodic site inspection or maintenance. The contractor provides a one-year warranty on installation labor. Cosmetic defects, impact damage and loads well above normal operation are excluded, and repairs or changes to the products by others void the warranty.
QuakeWrap® fabrics, QuakeBond™ resins, PileMedic® laminates, StifPipe® and SPiRe®+ panels: each current product data sheet carries the same warranty. QuakeWrap, Inc. warrants the product for one year from the date of installation to be free from manufacturing defects and to meet the properties on the current data sheet, when used as directed within its shelf life. The user decides whether the product suits the intended use. The remedy is limited to the purchase price or replacement of the product, not labor.
- Data sheets: one-year product warranty
- SPiRe®+ specification: two-year material warranty
- Contractor: one-year labor warranty

Specification Questions
Can I edit the specifications?
Yes. The PileMedic® and SPiRe®+ specifications come in MS Word. Ask us for a Word copy of the Composite Strengthening System specification. The generic PileMedic® specification is written in a non-proprietary format: delete the sections that do not apply and keep the one option you plan to use.
Which specification covers carbon and glass fabric wraps?
The QuakeWrap® Composite Strengthening System specification, formerly called the wet layup specification. It covers carbon and glass fabrics saturated with epoxy in the field and bonded to concrete and masonry, and references ACI 440.2R-23.
Are the sample design details ready for construction?
No. They are typical details marked Not for Construction, with the Designed and Approved By block left blank. Your engineer of record adapts layers, overlaps, reinforcement and terminations to the project.
Which specification covers the grout inside a jacket?
Section 03 30 12. The grout specification is not a separate system: it supports the PileMedic® and SPiRe®+ systems and covers cementitious grout, epoxy grout and cellular concrete. The PileMedic® specification explains when to use low-viscosity resin, epoxy grout or underwater grout.
What if I don't see a specification for my product?
Ask for it. Our team will recommend the right QuakeWrap® system and send the specifications and details your engineer needs.
What warranty comes with QuakeWrap® products?
The SPiRe®+ specification calls for a two-year material warranty and a one-year contractor labor warranty. Ask for the current warranty terms for other products with your specification package.
